Forged Alloy Components
Ring-rolled, upset and open-die forgings from 5 kg to 3,000 kg in nickel, cobalt and precision alloys.
Forging Capabilities
§01 — OverviewRAS Alloy produces forged rings, discs, shafts, blocks and custom shapes in heat-resistant and corrosion-resistant alloys. Our forging lines cover upsetting, ring-rolling, open-die and closed-die processes with integrated heat treatment and NDT.
Key Capabilities
- Weight range
- 5 kg – 3,000 kg
- Ring OD
- Up to 2,500 mm
- Max length
- Up to 6,000 mm
- Heat treatment
- Solution + age, anneal, stress-relief
- NDT
- UT, MT, PT, dimensional CMM
Why RAS Alloy
§02 — Quality + TraceabilitySizes & Tolerances
§03 — Specifications| Type | Range | Note |
|---|---|---|
| Rings | OD 100 – 2,500 mm | Wall 15 – 400 mm |
| Discs | Ø 100 – 1,200 mm | Thickness 30 – 600 mm |
| Shafts | Ø 50 – 500 mm | Length up to 6,000 mm |
| Custom blocks | By drawing | 5 kg – 3,000 kg |
Tolerances
- Dimensional
- ASTM B564 / customer PO
- Surface finish
- Ra 6.3 – 25 as forged
- Machined finish
- Ra 0.8 – 3.2 on request
Typical End Uses
§04 — ApplicationsFrequently Asked Questions
Forging FAQWhat forging sizes can you produce in Inconel 718 and other nickel alloys?
Open-die, upset and ring-rolled forgings run from 5 kg to 3,000 kg: rings up to 2,500 mm OD with 15–400 mm wall, discs to Ø1,200 mm and shafts to Ø500 mm × 6,000 mm length. Every delivery includes solution + age or annealed heat treatment, UT/MT/PT inspection and a mill test certificate traceable to the furnace batch.
Which standards govern your nickel alloy forgings and flanges?
Forgings are supplied to ASTM B564 and ASME B16.5, with age-hardened grades per AMS 5662 (Inconel 718) and AMS 5708 (Waspaloy). Sour-service items carry NACE MR0175 qualification; flanges ship with PMI report and hydrostatic test documentation on request.
Can you supply machined forgings for subsea and downhole service?
Yes. We deliver rough or finish-machined blocks, wellhead connectors and pump shafts in Inconel 718, Inconel 625 and Monel K-500 to NACE MR0175 hardness limits, with CMM dimensional reports and full heat traceability.
